ColorMax^EBooths: "E" for engineered. Whether your products are very large or very small, or require a special arrangement of manual or robotic coating stations, these ColorMax^E  booth deliver reliable powder containment, highest recovery efficiency, and contamination-free color change drawing on 50+ years of Nordson booth design experience.

ColorMax³ Booths: Most popular and versatile fast color change system combining reliable powder containment, over 95% recovery efficiency, and superior color change quality. Flexible configuration of manual or robotic coating stations. Gentle downdraft airflow is evenly distributed along the booth base for high application efficiency.

ColorMax²Booths: broad range of configurations for manual touch-up or robot coating stations. High color change quality with multiple access points to powder recovery systems. AeroDecks? provide full access to the air-intake ducts inside the booth. Split cyclones with full internal access ensure the highest color change quality even with high-contrast colours.

Horizon? series booths: space efficient design for the highest powder recovery efficiency with gentle downdraft airflow. Filter module integrated into the booth base for low powder in process and easy booth cleaning. Recommended for low to medium volume automatic powder coating operations with a limited number of colors. Aerodynamically optimized booth canopy ensures uniform airflow distribution throughout the booth.

Excel? 3000 booth: for the highest operating efficiency in medium to high volume powder coating systems with limited number of colors, the filter-based powder recovery systems deliver over 99% powder utilization. Open-face filter modules attach directly to the booth canopy minimizing the pressure drop in the recovery system for high energy efficiency. Aerodynamically optimized booth canopy design ensures uniform airflow distribution throughout the booth. Highly efficient, two-stage powder filtration process allows clean air to be returned into the plant. Unique filter media design maximizes the effective filtration area for long-lasting performance.

Booths for Powder Enameling: Gentle airflow, high application efficiency, minimum powder in process with gentle powder handling, and extreme durability are the key design requirements for powder enameling systems.

XXL Booths: With a vast experience in powder coating applications for ACE industry, Nordson designs single- or multi-color extra-large booth delivering reliable powder containment and optimum airflow for high powder application efficiency.

Lean Cell Booths: Advanced color change solutions demand special booth designs. The LeanCell series booths are designed specifically for integration with Nordson Color-On-Demand (COD), ultra fast color change spray systems. When changing powder colors in less than 30 seconds, the booth airflow must be optimized to ensure the previous color of powder is fully evacuated.

The compact Econo-Coat® powder spray booth and recovery system is perfect for batch powder coating small to medium sized parts.

The EcoMax is a range of compact, free-standing manual spray booths with cartridge recovery systems. Ideal solution from small batch to conveyorized production.

The Vantage FCM is a fixed collector module (FCM) powder spray booth that combines proven performance in a cost-effective design, making it ideal for job shops, start-up operations or to expand existing production economically.

Encore™ Feed Center: An open style feed center following "if you can see it, you can clean it" principle for easy cleaning to ensure contamination free color change. Designed with up to three solid lances for up to 27 Encore inline pumps with integrated pick-up tubes. Automatic lifting for smooth lance positioning. Compact design for optimum overall system foot print. Connects to the centralized booth exhaust system or, optionally available with an integrated filtration and fan section. Intuitive, ergonomically positioned controls for operator convenience.

Spectrum Feed Center: create a clean operating environment and ensure uninterrupted powder supply to the spray systems. The unique hopper design enables automatic purge-cleaning and full operator access for inspection following the cleaning cycle. The highest finish quality is assured by the use of a high-efficiency ultrasonic sieve for screening both reclaimed and fresh powders. Fresh powder is automatically added to the hopper using high-efficiency HDLV transfer pumps either directly from the original boxes or from other Nordson bulk-feed systems.

Large, open-face filter modules deliver gentle side-draft airflow in the spray area. This effectively evacuates over sprayed powder while enhancing powder application efficiency.

Proven in thousands of installations, the aerodynamically optimized booth canopy with efficiency extensions around the automatic gun openings and flared part-opening vestibules ensure reliable powder containment while minimizing the overall system footprint.

Dieletric booth canopy does not attract electric field or charged powder. This further contributes to the high powder application efficiency.

Nordson HTM series powder feed hoppers gently fluidize powder for stable and efficient powder delivery. Sized to accommodate the required number of spray systems while optimizing the volume of powder in process.

Closely coupled to filter modules for effective venting and clean operating environment. Robust hopper design supports integration with a range of rotary, vibratory, or ultrasonic sieves. Both fresh and reclaimed powders are sieved for high finish quality.

PowderGrid? Plus filters combine a durable polyester media with a unique, self-supporting pleat design to maximize the effective filtration surface area for long lasting performance even with challenging powders. Center-mount design prevents over-tightening and significantly simplifies the filter change.

Filter modules are easily disconnected from the booth base. An inflatable gasket between the filter module and the fan section ensures no leaks and clean operating environment. Unique reverse-pulse nozzle design gently expels deposited powder from the filter media for over 99% reclaim efficiency.

Open-face filter-module design with no connecting ducts significantly reduces the pressure drop in the recovery system for high energy efficiency.

Pioneered by Nordson more than 40 years ago, the twin-cyclone systems are compact, accessible for color change, and recover over sprayed powder with over 95% efficiency.

This unique design ensures fast powder settlement in the recovery hopper when the two, counter rotating streams of powder exit the cyclones. This eliminates any chance of the recovered powder being recaptured by the cyclone vortex. High-capacity HDLV transfer pumps promptly remove powder from the recovery hopper and create negative pressure in the lower part of the cyclones for even greater efficiency.

Convenient access inside the cyclones enables contamination-free color change even with contrast colors and without the need for non-reclaim operation.

The airflow management inside the booth and meticulous selection of the materials for booth construction, ensure no powder accumulation inside the booth.

Patented Apoge™ composite material offers superior mechanical strength and minimum powder attraction for easy, automated blow-off and years of superior color change performance.

If you can see it - you can clean it. This is the principle followed by Nordson engineers when designing fast color change systems.

The minimum length connecting ducts with ergonomically positioned inspection doors and easy access inside the twin-cyclones enable contamination-free color changes without the need for non-reclaim operation following even  high-contrast colours changes. The powder recovery path is perfectly streamlined to eliminate undesirable connections which can retain powder.

When it comes to color change quality and powder recovery efficiency, Nordson ColorMax Series booths are second to none in the industry.

Reliable powder containment, soft airflow, and fast, contamination-free color change are key requirements for a modern powder coating booth design. We put over 50 years of design experiene into every system detail.

The containment airflow of Nordson ColorMax? Series booths exceeds the industry norms while. Evenly distributed, gentle airflow creates optimum conditions for efficient powder deposition.

The minimum length of the interconnecting ducts and twin-cyclone technology reduce the pressure drop within the recovery system for high energy efficiency.
